High power, fully automatic
Built in MPPT charger
Pure sine wave output
High power grid connected machine
Support valve regulated lead-acid battery pack
DC 360V input3-phase AC 500V output
Energy conservation and environmental protection
Automatic switching function
| MODEL | CCH 20KW |
| Phase | 1-phase |
| Max. PV input Power | 25000W |
| Rated Output Power | 20000W |
| Max. Solar Charging Current | 60A |
| PV Input(DC) | |
| Nominal DC Voltage/Maximum DC Voltage | 320VDC/500VDC |
| Start-up Voltage/lnitial Feeding Voltage | DC320V |
| MPPT Voltage Range | 380VDC~550VDC |
| Number Of MPPT Trachers/Max. input Current | 2 * 50A |
| GRID OUTPUT(AC) | |
| Nominal Output Voltage | AC220V |
| Output Voltage Range | 220/230/240VAC |
| Nominal Output Current | 67.5A |
| Power Factor | 98% |
| EFFICIENCY | |
| Max. Conversion Efficiency(DC/AC) | 98% |
| Full Load | 20000W |
| Main Load Retum Voltage | AC180V |
| OFF-GRID OPERATION | |
| AC Start-up Voltage/Auto Restart Voltage | AC180V |
| Acceptable Input Voltage Range | 180-245VCA |
| Max. AC Input Current | 70A |
| Nominal Operating Frequency | 50/60Hz |
| Surge Power | 30000W |
| PV INPUT (DC) | |
| Max. DC Voltage | DC450V |
| MPPT Voltage Range | 380VDC~550VDC |
| Number of MPPT Trackers/Max. Input Current | 2X60A |
| BATTERY MODE OUTPUT(AC) | |
| Nominal Output Voltage | DC320V |
| BATTERY & CHARGER | |
| Nominal DC Voltage | DC320V |
| Max. Solar Charging Current | 60A |
| Max. AC Charging Current | 70A |
| PHYSICAL | |
| Dimension.D*V*H(MM) | 430x500x205mm |
| Net Weight(kgs) | 22.3kg |
| Waterproof grade | IP20 |
| Number of MPPT | 1 |
