Pure sine wave output
Output power factor 1.0
Programmable supply priority for PV, battery or Grid
User-adjustable charge current and voltage
Wide PV input range (120Vdc -500Vdc),110A MPPT SCC
Working without batteries in sunny day
WiFi Monitoring Function (optional)
Anti-dusk kit for harsh environment(optional)
LCD remote control with 10 meters wire(optional)
PV and electricity complementary
Use with lithium batteries
| MODEL | CCO 5.5KW |
| Rated Power | 5500VA/5500W |
| INPUT | |
| Voltage | 230VAC |
| Selectable Voltage Range | 170-280VAC(for personal computers) 90-280VAC(for home appliances) |
| Frequency Range | 50Hz/60Hz (Auto sensing) |
| OUTPUT | |
| AC Voltage Regulation (Batt.Mode) | 230VAC±5% |
| Surge power | 11000VA |
| Efficiency(Peak) PV to INV | 97% |
| Transfer Time | 20ms (for home appliances) 10ms (for personal computers) |
| Wave form | Pure Sine Wave |
| Efficiency(Peak) BAT to INV | 94% |
| BATTERY & AC CHARGER | |
| Battery Voltage | 48VDC |
| Floating Charge Voltage | 54VDC |
| Overcharge Protection | 63VDC |
| Maximum charge current | 80A |
| SOLAR CHARGER | |
| Maximum PV Array Open Circuit Voltage | 500VDC |
| MAX.PV Array Power | 6000W |
| MPPT Range@ Operating Voltage | 120-500VDC |
| Maximum Charging Current | 110A |
| Maximum Efficiency | 98% |
| PHYSICAL | |
| Dimension.D*W*H(mm) | 472*297*129 |
| Net Weight (kgs) | 14kg |
| Communication Interface | RS485/RS232(Standard) LCD remote/WIFI(Optional) |
| OPERATING ENVIRONMENT | |
| Humidity | 5% to 95% Relative Humidity(Non-condensing) |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -15°C to 60°C |
